Degrees to text adjustment

Degrees to text adjustment

Usage

degrees_to_adj(
  degrees,
  top = 90,
  clockwise = FALSE,
  expand = 0,
  do_fractional = TRUE,
  bias_side = 1,
  bias_height = 1,
  plot_ranges = FALSE,
  ...
)

Arguments

degrees

numeric value for angles in degrees

top

numeric value indicating the angle at the top position

clockwise

logical indicating whether the angle increases in clockwise direction

expand

numeric value intended to expand the adjust value. For example expand=0.5 will expand the adjust value 50%.

do_fractional

logical whether to adjust fractional values along the outer edge, default TRUE. When FALSE, it "snaps" the label to either a right angle, or exact 45-degree angle relative to the incoming line segment.

bias_height, bias_side

numeric values used only when do_fractional=FALSE, which expands the range of degree angles where a label is pushed to a 45-degree angle. For example, when bias_side=2 the range of degrees on the left and right side are more likely to result in labels with 45-degree adjustment.

plot_ranges

logical whether to plot a visual with the angular cutoffs which define the adjustment.

...

additional arguments are ignored

Details

Utility function to define adj values suitable for text plotting, which arranges text relative to the angle in degrees.

See also

Other venndir geometry: diff_degrees(), display_angles(), mean_degree_arc(), mean_degrees(), rescale_coordinates(), spread_degrees(), three_point_angle()

Examples

degrees <- seq(from=1, to=360, by=10);
x <- cos(jamba::deg2rad(degrees));
y <- sin(jamba::deg2rad(degrees));

adjdfF <- degrees_to_adj(degrees, do_fractional=TRUE);
plot(x, y,
   main="Sliding edge adjustment.",
   pch=20, asp=1,
   xlim=c(-1.3, 1.3),
   ylim=c(-1.3, 1.3));
jamba::drawLabels(txt=seq_along(degrees),
   x=x, y=y, labelCex=0.8, boxColor="gold",
   adjX=adjdfF[,1], adjY=adjdfF[,2])


adjdf1 <- degrees_to_adj(degrees, do_fractional=FALSE, bias_side=1);
plot(x, y,
   main="Snap to nearest 45-degree angle adjustment.",
   pch=20, asp=1,
   xlim=c(-1.3, 1.3),
   ylim=c(-1.3, 1.3));
jamba::drawLabels(txt=seq_along(degrees),
   x=x, y=y, labelCex=0.8,
   adjX=adjdf1[,1], adjY=adjdf1[,2])


adjdf <- degrees_to_adj(degrees, bias_side=3, do_fractional=FALSE);
plot(x, y,
   main="Snap to 45-degree with custom bias.",
   pch=20, asp=1,
   xlim=c(-1.3, 1.3),
   ylim=c(-1.3, 1.3));
jamba::drawLabels(txt=seq_along(degrees),
   x=x, y=y, labelCex=0.8, boxColor="gold",
   adjX=adjdf[,1], adjY=adjdf[,2])


adjdf <- degrees_to_adj(degrees, bias_side=3,
   expand=c(1, 1), do_fractional=FALSE);
plot(x, y,
   main="Example using base text()",
   pch=20, asp=1, cex=0.4, col="red",
   xlim=c(-1.3, 1.3),
   ylim=c(-1.3, 1.3));
for (i in seq_along(degrees)) {
   text(labels=i,
      x=x[i], y=y[i],
      adj=unlist(adjdf[i,]))
}
